| Name：TFF-N20PAVA |
| Time：14-05-13 |
| Click： |
|
典型应用 |
Typical Applications Audio and Visual Equioments:MD Player/Car CD Player/Camcorder Precision Instruments: Camera Toys and Models: Motorized Toy/Motorized Plastic Model/Radio Control Model |
|
型号 MODEL |
电压 VOLTAGE |
空载NO- LOAD | 负载 AT MAXIMUM EFFICIENCY | 堵转STALL | ||||||||
| 转速 SPEED |
电流 CURRENT |
转速 SPEED |
电流 CURRENT |
转矩 TORQUE |
功率 OUTPUT |
转矩 TORQUE |
电流 CURRENT |
|||||
| 使用范围OPERATING RANGE | 额定值NOMINAL | r/min | A | r/min | A | mN·m | g·cm | W | mN·m | g·cm | A | |
| TFF-N20PA-10190 | DC 2.0-5.0V | DC 3V | 12100 | 0.045 | 9390 | 0.16 | 0.21 | 2.1 | 0.20 | 0.92 | 9.4 | 0.54 |
| TFF-N20PA-08260 | DC 1.5-6.0V | DC 3V | 8200 | 0.040 | 5920 | 0.10 | 0.71 | 1.8 | 0.11 | 0.62 | 6.3 | 0.27 |
